Switchpointheating VärmeKabelTeknik



6

Assemblyinstructions



Fitthenextchanneltightlyagainstthefirstone,anditis

agoodideatomakeaclipcoverthejoint.

Continueuntilthewholeelementincludingthe

connectioncablejointiscovered.



Fornarrowpassagesflexiblechannelsareusedwhich

canbebenttofit.

Hereitmayalsobenecessarytousebothtypesofclips

toachievethebestpossiblecontact.



Repeattheprocedurefortheotherstock‐railandfor

thetwomovingrails.



Insomeextremecaseswheretheswitchisinan

exposedpositionwithheavywindsorwherelarge

amountsofsnowcanbeexpected,anextraelementis

mountedonthemovingrail.Thiselementismounted

onthesidefacingthestock‐rail.

Thelengthofthiselementcanbe

approximatelyhalf

thelengthchosenfortheotherelements.




