Switchpointheating VärmeKabelTeknik



4

Components



Velox protective cover

Toprotectthe4‐wayblockfrommechanicaldamagefor

examplewhenpowerbrushingrail.



Cable joint

Isusedtoconnecttwocableswithoutuseof

shrinkingtubeorfillingcompound.

Thecablejointisadryjointandveryeasytouse.

Thecablejointisprovidedwith2glandsPG29,IP65.

max.cablediameter:dependingonglandused.

Thisjointcanbeusedforanycableuptoamax.

diameterof

thesizea40mmglandcantake.Ifrequired

smallerglandscanbesuppliedtogetherwithreducer

from40mm.



Junction box

Waterproofjunctionbox.


