VärmeKabelTeknik Switchpointheating



Assemblyinstructions



Measurethelengthofthepartoftheswitchwhichistobeheated.

Findouttherailtypeinquestion.

Decideifanexistingcontrolsystemcanbeused(230Vtotheelement)orifanewonehastobebought.

Ifanewcontrolsystemmustbebought,

findoutwhichfunctionsarerequired,(typeofcontrol,log‐ging,remotecontrol

bytelephonewireormobilemodem,etc).

Sendafaxwiththeaboveinformationtousonourfaxnumber:+46‐(0)301‐41870oremail:[email protected]forhandling,

quotationandorder.



Whenallmaterialhasbeen

delivered,checkthatall

componentsaresuppliedandthatthemarkingonthe

heatingcablecorrespondstothelengthyouordered.

Eachheatingelementhasaseparatemarkingenabling

youtoeasilyreplaceadamagedelement.



Prepareaswitchthatisinusebybrushingtherailfoot

(wheretheelementsandclipsaretobemounted)with

asteelbrushtoobtaingoodcontact.

Reelouttheelementwiththeconnectiondevice

furthestawayfromthetonguetip,andputthecable

channelnextto

therail.

Takeoutthecorrectclips

Typeexample13‐43‐69forstock‐rail

Typeexample20‐43‐72formovingrail



Startbymountingtheterminationendoftheelement.

Thefirstchannelhastocovertheendtermination.

Fastentheclipsbycarefullyknockingtheminposition

(seeillustration)orbyusingamountingtoolforrail

clips.

Mount4clipstoeachmetre,spacedoutasevenlyas

possible.

NOTE!

Inapplicationswherepointrodheatersaretobe

mounted,theelementforthestock‐railhasbeenfitted

withaconductorjoint.




