Further Accessories

Rutronik number Product type Suitable for Description

WIREAC1013 System connector GC864-QUAD-C2 60P Female Header SMT 1.27 mm

WIREAC1014 System connector GC864-QUAD-C2 60P Female Header hole m. 1.27 mm

COREC19998 System connector GSM (GM862) 50P Female Header SMT

COREC21477 System connector GSM (GC864) 80P Female Header SMT

System Connectors

WIREAC1033 Adapter cable GSM MMCX male R/A to SMA/f bulkhead, 100 mm

WIREAC1036 Adapter cable GSM MMCX male R/A to SMA/f bulkhead, 150 mm

WIREAC1079 Adapter cable GC864-QUAD GSC to SMA/f bulkhead, 100 mm

Adapter Cables

WIREAC1025 Antenna GPS Magnetic antenna, 5 m cable, SMA male

WIREAC1027 Antenna GSM Glass antenna, T-shape, 3 m cable, SMA male, 900/1800 MHz

WIREAC1028 Antenna GSM Glass antenna, I-shape, 3 m cable, SMA male, 900/1800 MHz

WIREAC1029 Antenna GSM Magnetic antenna, 3 m cable, SMA male, 900/1800 MHz

WIREAC1031 Antenna GSM Stub antenna, straight, 56 mm, SMA male, 900/1800 MHz

WIREAC1032 Antenna GSM Stub antenna, angled, 54 mm, SMA male, 900/1800 MHz

WIREAC1035 Antenna GSM Swivel antenna, 104 mm, SMA male, 900/1800 MHz

WIREAC1004 Antenna GSM PCB antenna, MMCX male R/A, 900/1800/1900MHz

Antennas

WIREAC1009 Simcard holder GSM 6P spring-ejection mechanism with lock and sim card detection

WIREAC1015 Simcard holder GSM 6P spring-ejection mechanism and sim card detection

WIREAC1039 Simcard holder GSM 6P with cover and sim card detection

WIREAC1040 Simcard holder GSM 6P with cover and sim card detection (side connected)

WIREAC1078 Simcard holder GSM 6P spring-ejection mechanism and simcard detection

SIM Card Holders

WIREAC1026 Antenna GSM Hole mounted antenna, 3 m cable, SMA male, 900/1800 MHz

Antennas and adapter cables are also available with other types of connectors
