Accessories

Mobile Communication- & Telematics-Antennas from Hirschmann

GPS 7 M

GPS

■ Magnetic surface mount

antenna

■ Dimensions: 39 x 39 x 14 mm

■ Voltage Supply: 3 - 5.5 VDC

■ Gain: 2 dBic

■ Amplifications: 26 dB ± 2 dB typ.

■ Cable: RG 174, L=3000 mm

■ Connector:

- 001: MCX male

- 002: SMB female

- 003: SMA male

- 004: FAKRA female,

Code C

GPS 1890

GPS, AMPS GSM 900/1800/1900

■ For navigation, traffic telematics

or fleet management

■ Easy mounting by adhesive or

magnetic pad

■ Mounting on various surfaces

(glass, plastic, metal, etc.)

■ Dimensions:

100 x 66 x 19 mm

GPS:

■ Voltage Supply: 3 - 5.5 VDC

■ Gain: 2 dBic

■ Amplifications: 27 dB ± 2 dB

AMPS

GSM 900/1800/1900

UMTS

■ Gain: 0 dBi

MCA 18 90 MH

AMPS, GSM 900/1800/1900, UMTS

■ Easy interior windscreen mounting,

self-adhesive

■ Doesn’t interfere the car design

■ Dimensions: x 57 mm

■ Gain: 0 dB

■ Cable: RG 174, L=2500 mm

■ Connector: FME female

■ GPS

■

GSM/Celluar

■

WLAN & BLUETOOTH

■

TETRA

■

ORBCOMM

■

Cables

■

Adapters

full

availability

This is only a short extract from the HIRSCHMANN portfolio.

Rutronik offers the complette range of antennas & accessories.
