Wavecom Instruments Fully Integrated Test n Print Unit User Manual
14
Site x
Search Barcode
0000000 5000
Type in or scan the barcode number to be searched and press enter. If the screen
displays new barcode press enter to switch over. The screen can only be switched
if there is no entry.
The existing record details will be shown. Any changes made here will be updated
once the site is downloaded in WinPATS. If nothing needs changing hold the enter
key to proceed to the next screen.
Visual Check
xx/xx/xxxx xx:xx
Out of Services
Fail Pass
After all item details have been entered, hold the enter key for 2 seconds to
proceed to the Visual Check screen. After the item has been visually inspected,
there is 1 of 3 options that can be selected; Out of Service (F2), Fail (F3) and Pass
(enter). If Out of Services or Fail is selected the result will be saved and the TnP
will revert back to the barcode entry screen. If you have a zebra printer a tag will
be printed. If the test is a visual check only then press (enter hold). See add
equipment for details.
Main Menu A
Earthed Test
D/Insulated Test
Lead Test (Ext Lead Test)
If the item passes a visual inspection and pass is selected, testing can begin.
Test Results
Earthbond Pass
Insulation Pass
Once test has completed the results are displayed.
To test the item multiple times press (F3) this will take you back to the main menu
A screen. From here you can choose a test class. You would use this for example
if testing power boards. To complete the test press (enter). This will take you back
to the search barcode screen. If you have a zebra printer a barcode will be printed
once (enter) is pressed.
To download records using WinPATS software, please refer to the Downloading Records section of the
WinPATS manual
Deleting Equipment
If for some reason a record needs to be deleted it can be removed from the search barcode screen. This feature
removes the whole record and not just the test results. If a record is deleted and replaced it might create a new
record when downloaded in WinPATS. This is because the record details didn't match the original ones. Multiple
items cannot be deleted at the same time.
Site x
Search Barcode
0000435 4535
From the search barcode screen press and hold the enter key. Then press the F1
key. The feature cannot be selected when new barcode is displayed.
Site x
S/Record Del.
0000435 4535
The search barcode will change to S/Record Del. Scan or type the barcode that
needs to be deleted. If the record does not exist or is in the wrong site a message
will be displayed saying nothing was found.
Delete Record?
[barcode]
Hold F3 to Delete
Delete Quit
When a match is found a last warning message will be displayed. To delete the
record hold the F3 key for 2 seconds. To cancel press enter.
