Wavecom Instruments Fully Integrated Test n Print Unit User Manual

Entering Items

Screen

Instruction

Site x

New Barcode

0000000 5000

Type in the new barcode or press F3 quickly to choose the auto generate number.

Once a barcode has been specified, items can be entered. If the screen displays

"search barcode" press enter to switch to new barcode. There must be no numbers

entered in to switch between the two modes.

Loc | Desc | Make

A selection of details can be entered for an item. Details include; location,

description, make, model, serial number, asset number, frequency of test and

notes. Each heading relates to an 'F'; e.g. Loc = F1, Desc = F2 and Make =

F3. Only 3 items are displayed at one time. To scroll through the various details,

press enter key. By continually pressing enter you can loop back to the first 3

items. Please make sure location, description are filled out and check to see that

the frequency is correct. Once the details are entered hold the enter key for 2

seconds to move on to the visual check screen.

Location ALP

Entering an items details is the same process as entering sites and users, please

refer to the Adding a Site/User steps above. Ensure that test frequency for the

item is set in accordance with the AS/NZ 3760 Standard

Visual Check

xx/xx/xxxx xx:xx

Out of Services

Fail Pass

After the item has been visually inspected, there is 1 of 3 options that can be

selected; Out of Service (F2), Fail (F3) and Pass (enter). If Out of Service or Fail is

selected the result will be saved and the TnP will revert back to the barcode entry

screen. If you have a zebra printer a tag will be printed. If the test is a visual check

only then press (enter hold). See below for details.

Main Menu A

Earthed Test

D/Insulated Test

Lead Test (Ext Lead Test)

If the item passes a visual inspection and pass is selected, testing can begin.

Select the correct test based on the appliance type.

Test Results

Earthbond Pass

Insulation Pass

Once test has been completed the results are displayed.

What Next?

Re-Test Cont.

To test the item multiple times press (F3). This will take you back to the main

menu A screen. From here you can choose a test class. You would use this for

example if testing power boards. To complete the test press enter. This will take

you back to the new barcode screen.

If you have a zebra printer a barcode will be printed once (enter) is pressed.

Visual Check Only Option

Visual Check

xx/xx/xxxx xx:xx

Out of Services

Fail Pass

Items can be passed with a visual check only (no testing required). You must be at

the visual check screen shown on the left. To do a visual check only press and hold

(enter) for 2 seconds.

Visual Check

Only?

Save and Exit

Yes No

Pressing (enter) will take you back to the visual check screen. Pressing (F3) will

complete the test. Print out a tag if you have a zebra printer. Then go back to the

new barcode screen.

Retesting Equipment

The following must be done before retesting:

 A site must exist in the tester with records. A site is usually uploaded from WinPATS.

 The correct site must be displayed on the first line of the new / search barcode screen. If the incorrect

site is displayed no equipment will be reported when scanned. To change see the add sites section.

The correct user must be selected from the users list. A user is important because it give a reference to the test

results in WinPATS. It is also the user that is displayed on the tag. If there is no users create a users as

described in the add equipment section or upload the users list from WinPATS.
