Integra M2106+

Erreur ! Style non défini.

©Confidential

Page: 13 / 77

This document is the sole and exclusive property of Wavecom. Not to be distributed or divulged without prior written

agreement.

WA_DEV_M2106+_PTS_003-001 April, 2007

2 General Description

2.1 Presentation

The Integra M2106+ Wireless CPU

is a self-contained E-GSM/GSM-GPRS 900/1800 dual-band Wireless

CPU

and is GPRS class 10 capable.

Figure 1: M2106+ view

It includes a Quik Q24 Wireless CPU

and its interfaces are available through:

• A 50-pin connector for Baseband analog and digital interfaces (General Purpose Connector)

• A RF connector, MMCX type

• A SIM card holder

connector

SIM card

holder

50-pin

connector

Figure 2: Integra M2106+ Wireless CPU

connectors

The mating connectors for the General Purpose connector and RF connector are standard and easy-to-find.
